TRUMPF TRUTOOL TF 350

A fast, reliable tool for joining metal sheets without screws or rivets. The TruTool TF 350 joins coated or uncoated sheet metal in a single stroke using cold forming—delivering a strong, corrosion-resistant connection with no need for consumables.

Uses:

• Joining ducts and ventilation flanges
• Connecting up to three sheets, even of varying thicknesses
• Ideal for HVAC and sheet metal fabrication
• Works equally well on coated or uncoated materials

Product Details:

• Cold-formed joints—no rivets, screws, or adhesives
• One-step joining saves time and reduces cost
• Consistent joint quality and corrosion resistance
• Joins material thicknesses from 0.8 mm to 4.0 mm
• Lead time: 3–4 weeks
• 5-year warranty (register online)
• Made in Switzerland
• Available in two models: Corded and 18V LiHD Battery

TRUMPF TRUTOOL TF 350 (Corded)

Technical Data:

• Max sheet thickness (steel 400 N/mm²): 3.5 mm
• Max sheet thickness (steel 600 N/mm²): 2.5 mm
• Max sheet thickness (aluminium 250 N/mm²): 4.0 mm
• Min sheet thickness: 0.8 mm
• Weight: 8.3 kg
• Length: 426 mm
• Height: 358 mm

TRUMPF TRUTOOL TF 350 (18V LiHD Battery)

Technical Data:

• Max sheet thickness (steel 400 N/mm²): 3.5 mm
• Max sheet thickness (steel 600 N/mm²): 2.5 mm
• Max sheet thickness (aluminium 250 N/mm²): 4.0 mm
• Min sheet thickness: 0.8 mm
• Weight with battery: 8.0 kg
• Length: 454 mm
• Height: 358 mm
