JOUANEL DECOILER – SECOND HAND

JOUANEL DECOILER – SECOND HAND

The Jouanel Manual Decoiler is a robust and reliable tool designed for unwinding metal coils with ease and precision. Perfect for roofing and construction tasks, this second-hand machine is available in two versions: one with integrated lifting holes for forklift or crane handling, and one without lifting holes for standard mobility needs. Both models are equipped with a manual expansion system and swivel wheels with brakes, making them ideal for stable, smooth operation in any environment.

Uses:

• Ideal for unwinding metal coils in roofing and construction applications
• Suitable for use in workshops and job sites requiring mobility and precise coil handling
• Manual operation for expanding and adjusting the mandrel size (from Ø 285 to 540 mm)

Product Details – Jouanel Decoiler on Wheels with lifting holes:

• Lifting holes for easy handling by forklift or crane
• Equipped with 4 swivelling wheels, each with a brake for easy mobility and stability
• Wheel axis mounted on ball bearings
• Manual expansion from Ø 285 to 540 mm
• Maximum external diameter of the coil: 1000 mm
• Manual brake on the same side as the handle for quick and easy adjustment
• Allows rewinding without action on the hub expander
• Maximum load capacity: 1000 kg
• Net weight: 130 kg
• Net weight of one expanding hub: 86 kg

Product Details – Jouanel Decoiler on Wheels without lifting holes:

• Equipped with 4 swivelling wheels, each with a brake for easy mobility and stability
• Wheel axis mounted on ball bearings
• Manual expansion from Ø 285 to 540 mm
• Maximum external diameter of the coil: 1000 mm
• Manual brake on the same side as the handle for quick and easy adjustment
• Allows rewinding without action on the hub expander
• Maximum load capacity: 1000 kg
• Net weight: 130 kg
• Net weight of one expanding hub: 86 kg

Models:

Jouanel Decoiler on Wheels with lifting holes – SKU DVS1250PMLH

Jouanel Decoiler on Wheels without lifting holes – SKU DVS1250PM
